CALPORT 300

The CALPORT 300 is a accuracy class 0.05 Reference Standard and an universal test system for the comprehensive investigation and commissioning of all components of a modern metering installation.

SKU: CALPORT-300 Category:
Technical information for CALPORT 300



Auxiliary voltage: 86 … 264 V, 47 … 65 Hz
Power consumption: approx. 40 VA
Housing: Hard plastic housing
Dimensions: W 450 x H 180 x D 300 mm
Weight: approx. 7 kg
Influence of auxiliary voltage
on the measuring results:		 ≤ 0.005 % at 10 % variation
Ambient temperature: -10°C … +60°C
